Block Exchange Protocol v1
Introduction and Definitions
The Block Exchange Protocol (BEP) is used between two or more devices thus forming a cluster. Each device has one or more folders of files described by the local model, containing metadata and block hashes. The local model is sent to the other devices in the cluster. The union of all files in the local models, with files selected for the highest change version, forms the global model. Each device strives to get its folders in sync with the global model by requesting missing or outdated blocks from the other devices in the cluster.
File data is described and transferred in units of blocks, each being from 128 KiB (131072 bytes) to 16 MiB in size, in steps of powers of two. The block size may vary between files but is constant in any given file, except for the last block which may be smaller.
The keywords “MUST”, “MUST NOT”, “REQUIRED”, “SHALL”, “SHALL NOT”, “SHOULD”, “SHOULD NOT”, “RECOMMENDED”, “MAY”, and “OPTIONAL” in this document are copyright of the International English Language.
Transport and Authentication
BEP is deployed at the highest level in a protocol stack, with the lower-level protocols providing encryption and authentication.
+-----------------------------+
| Block Exchange Protocol |
|-----------------------------|
| Encryption & Auth (TLS 1.2) |
|-----------------------------|
| Reliable Transport |
|-----------------------------|
v ... v
The encryption and authentication layer SHALL use TLS 1.2 or a higher revision. A strong cipher suite SHALL be used, with “strong cipher suite” being defined as being without known weaknesses and providing Perfect Forward Secrecy (PFS). Examples of strong cipher suites are given at the end of this document. This is not to be taken as an exhaustive list of allowed cipher suites but represents best practices at the time of writing.
The exact nature of the authentication is up to the application, however it SHALL be based on the TLS certificate presented at the start of the connection. Possibilities include certificates signed by a common trusted CA, preshared certificates, preshared certificate fingerprints, or certificate pinning combined with some out-of-band first verification. The reference implementation uses preshared certificate fingerprints (SHA-256) referred to as “Device IDs”.
There is no required order or synchronization among BEP messages except as noted per message type - any message type may be sent at any time and the sender need not await a response to one message before sending another.
The underlying transport protocol MUST guarantee reliable packet delivery.
In this document, in diagrams and text, “bit 0” refers to the most significant bit of a word; “bit 15” is thus the least significant bit of a 16-bit word (int16), and “bit 31” is the least significant bit of a 32-bit word (int32). Non-protocol buffer integers are always represented in network byte order (i.e., big endian) and are signed unless stated otherwise, but when describing message lengths negative values do not make sense and the most significant bit MUST be zero.
The protocol buffer schemas in this document are in the proto3
syntax. This means, among other things, that all fields are optional and will assume their default value when missing. This does not necessarily mean that a message is valid with all fields empty - for example, an index entry for a file that does not have a name is not useful and MAY be rejected by the implementation. However the folder label is for human consumption only so an empty label should be accepted - the implementation will have to choose some way to represent the folder, perhaps by using the ID in its place or automatically generating a label.
Pre-authentication messages
AFTER establishing a connection, but BEFORE performing any authentication, devices MUST exchange Hello messages.
Hello, messages are used to carry additional information about the peer, which might be of interest to the user even if the peer is not permitted to communicate due to failing authentication. Note that the certificate-based authentication may be considered part of the TLS handshake that precedes the Hello message exchange, but even in the case that a connection is rejected a Hello message must be sent before the connection is terminated.
Hello, messages MUST be prefixed with an int32 containing the magic number 0x2EA7D90B, followed by an int16 representing the size of the message, followed by the contents of the Hello message itself.
0 1
0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5
+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+
| Magic |
| (32 bits) |
+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+
| Length |
+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+
/ /
\\ Hello \\
/ /
+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+
The Hello message itself is in protocol buffer format with the following schema:
message Hello {
string device\_name \= 1;
string client\_name \= 2;
string client\_version \= 3;
}
Fields
The device_name is a human-readable (configured or auto-detected) device name or host name, for the remote device.
The client_name and client_version identify the implementation. The values SHOULD be simple strings identifying the implementation name, as a user would expect to see it, and the version string in the same manner. An example client name is “syncthing” and an example client version is “v0.7.2”. The client version field SHOULD follow the patterns laid out in the Semantic Versioning standard.
Immediately after exchanging Hello messages, the connection MUST be dropped if the remote device does not pass authentication.
Post-authentication Messages
Every message post-authentication is made up of several parts:
- A header length word
- A Header
- A message length word
- A Message
0 1
0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5
+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+
| Header Length |
+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+
/ /
\\ Header \\
/ /
+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+
| Message Length |
| (32 bits) |
+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+
/ /
\\ Message \\
/ /
+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+
The header length word is 16 bits. It indicates the length of the following Header message. The Header is in protocol buffer format. The Header describes the type and compression status of the following message.
The message is preceded by the 32-bit message length word and is one of the concrete BEP messages described below, identified by the type field of the Header.
As always, the length words are in network byte order (big-endian).
message Header {
MessageType type \= 1;
MessageCompression compression \= 2;
}
enum MessageType {
CLUSTER\_CONFIG \= 0;
INDEX \= 1;
INDEX\_UPDATE \= 2;
REQUEST \= 3;
RESPONSE \= 4;
DOWNLOAD\_PROGRESS \= 5;
PING \= 6;
CLOSE \= 7;
}
enum MessageCompression {
NONE \= 0;
LZ4 \= 1;
}
When the compression field is NONE, the message is directly in protocol buffer format.
When the compression field is LZ4, the message consists of a 32-bit integer describing the uncompressed message length followed by a single LZ4 block. After decompressing the LZ4 block it should be interpreted as a protocol buffer message just as in the uncompressed case.
Message Subtypes
Cluster Config
This informational message provides information about the cluster configuration as it pertains to the current connection. A Cluster Config message MUST be the first post-authentication message sent on a BEP connection. Additional Cluster Config messages MUST NOT be sent after the initial exchange.
Protocol Buffer Schema
message ClusterConfig {
repeated Folder folders \= 1;
}
message Folder {
string id \= 1;
string label \= 2;
bool read\_only \= 3;
bool ignore\_permissions \= 4;
bool ignore\_delete \= 5;
bool disable\_temp\_indexes \= 6;
bool paused \= 7;
repeated Device devices \= 16;
}
message Device {
bytes id \= 1;
string name \= 2;
repeated string addresses \= 3;
Compression compression \= 4;
string cert\_name \= 5;
int64 max\_sequence \= 6;
bool introducer \= 7;
uint64 index\_id \= 8;
bool skip\_introduction\_removals \= 9;
bytes encryption\_password\_token \= 10;
}
enum Compression {
METADATA \= 0;
NEVER \= 1;
ALWAYS \= 2;
}
Fields (Cluster Config Message)
The folders field contains the list of folders that will be synchronized over the current connection.
Fields (Folder Message)
The id field contains the folder ID, which is the unique identifier of the folder.
The label field contains the folder label, the human-readable name of the folder.
The read_only field is set for folders that the device that will accept no updates from the network for.
The ignore_permissions field is set for folders that the device will not accept or announce file permissions for.
The ignore_delete field is set for folders that the device will ignore deletes for.
The disable_temp_indexes field is set for folders that will not dispatch and do not wish to receive progress updates about partially downloaded files via Download Progress messages.
The paused field is set for folders that are currently paused.
The devices field is a list of devices participating in sharing this folder.
Fields (Device Message)
The device id field is a 32-byte number that uniquely identifies the device. For instance, the reference implementation uses the SHA-256 of the device X.509 certificate.
The name field is a human-readable name assigned to the described device by the sending device. It MAY be empty and it need not be unique.
The list of addresses is used by the sending device to connect to the described device.
The compression field indicates the compression mode in use for this device and folder. The following values are valid:
Compress metadata. This enables compression of metadata messages such as Index.
Compression disabled. No compression is used on any message.
Compress always. Metadata messages as well as Response messages are compressed.
The cert_name field indicates the expected certificate name for this device. It is commonly blank, indicating to use of the implementation default.
The max_sequence field contains the highest sequence number of the files in the index.
The introducer field is set for devices that are trusted as cluster introducers.
The index_id field contains the unique identifier for the current set of index data.
The skip_introduction_removals field signifies if the remote device has opted to ignore introduction removals for the given device. This setting is copied across as we are being introduced to a new device.
The encryption_password_token field contains a token derived from the password, that is used to encrypt data sent to this device. If the device is the same as the device sending the message, it signifies that the device itself has encrypted data that was encrypted with the given token. It is empty or missing if there is no encryption.
Index and Index Update
The Index and Index Update messages define the contents of the senders folder. An Index message represents the full contents of the folder and thus supersedes any previous index. An Index Update amends an existing index with new information, not affecting any entries not included in the message. An Index Update MAY NOT be sent unless preceded by an Index unless a non-zero Max Sequence has been announced for the given folder by the peer device.
The Index and Index Update messages are currently identical in format, although this is not guaranteed to be the case in the future.
Protocol Buffer Schema
message Index {
string folder \= 1;
repeated FileInfo files \= 2;
}
message IndexUpdate {
string folder \= 1;
repeated FileInfo files \= 2;
}
message FileInfo {
string name \= 1;
FileInfoType type \= 2;
int64 size \= 3;
uint32 permissions \= 4;
int64 modified\_s \= 5;
int32 modified\_ns \= 11;
uint64 modified\_by \= 12;
bool deleted \= 6;
bool invalid \= 7;
bool no\_permissions \= 8;
Vector version \= 9;
int64 sequence \= 10;
int32 block\_size \= 13;
repeated BlockInfo Blocks \= 16;
string symlink\_target \= 17;
}
enum FileInfoType {
FILE \= 0;
DIRECTORY \= 1;
SYMLINK\_FILE \= 2 \[deprecated \= true\];
SYMLINK\_DIRECTORY \= 3 \[deprecated \= true\];
SYMLINK \= 4;
}
message BlockInfo {
int64 offset \= 1;
int32 size \= 2;
bytes hash \= 3;
uint32 weak\_hash \= 4;
}
message Vector {
repeated Counter counters \= 1;
}
message Counter {
uint64 id \= 1;
uint64 value \= 2;
}
Fields (Index Message)
The folder field identifies the folder that the index message pertains to.
The files field is a list of files making up the index information.
Fields (FileInfo Message)
The name is the file name path relative to the folder root. Like all strings in BEP, the Name is always in UTF-8 NFC regardless of operating system or file system-specific conventions. The name field uses the slash character (“/”) as a path separator, regardless of the implementation’s operating system conventions. The combination of folder and name uniquely identifies each file in a cluster.
The type field contains the type of the described item. The type is one of file (0), directory (1), or symlink (4).
The size field contains the size of the file, in bytes. For directories and symlinks the size is zero.
The permissions field holds the common Unix permission bits. An implementation MAY ignore or interpret these as is suitable on the host operating system.
The modified_s time is expressed as the number of seconds since the Unix Epoch (1970-01-01 00:00:00 UTC). The modified_ns field holds the nanosecond part of the modification time.
The modified_by field holds the short id of the client that last made any modification to the file whether add, change, or delete. This will be overwritten every time a change is made to the file by the last client to do so and so does not hold history.
The deleted field is set when the file has been deleted. The block list SHALL be of length zero and the modification time indicates the time of deletion or, if the time of deletion is not reliably determinable, the last known modification time.
The invalid field is set when the file is invalid and unavailable for synchronization. A peer MAY set this bit to indicate that it can temporarily not serve data for the file.
The no_permissions field is set when there is no permission information for the file. This is the case when it originates on a file system that does not support permissions. Changes to only permission bits SHOULD be disregarded on files with this bit set. The permissions bits MUST be set to the octal value 0666.
The version field is a version vector describing the updates performed to a file by all members in the cluster. Each counter in the version vector is an ID-value tuple. The ID is the first 64 bits of the device ID. The Value is a simple incrementing counter, starting at zero. The combination of Folder, Name, and Version uniquely identifies the contents of a file at a given point in time.
The sequence field is the value of a device's local monotonic clock at the time of the last local database update to a file. The clock ticks on every local database update, thus forming a sequence number over database updates.
The block_size field is the size, in bytes, of each block in the block list (except, possibly, the last block). If this field is missing or zero, the block size is assumed to be 128 KiB (131072 bytes). Valid values of this field are the powers of two from 128 KiB through 16 MiB.
The blocks list contains the size and hash for each block in the file. Each block represents a block_size-sized slice of the file, except for the last block which may represent a smaller amount of data. The block list is empty for directories and symlinks.
The symlink_target field contains the symlink target, for entries of symlink type. It is empty for all other entry types.
Request
The Request message expresses the desire to receive a data block corresponding to a part of a certain file in the peer’s folder.
Protocol Buffer Schema
message Request {
int32 id \= 1;
string folder \= 2;
string name \= 3;
int64 offset \= 4;
int32 size \= 5;
bytes hash \= 6;
bool from\_temporary \= 7;
}
Fields
The id is the request identifier. It will be matched in the corresponding Response message. Each outstanding request must have a unique ID.
The folder and name fields are as documented for the Index message. The offset and size fields specify the region of the file to be transferred. This SHOULD equate to exactly one block as seen in an Index message.
The hash field MAY be set to the expected hash value of the block. If set, the other device SHOULD ensure that the transmitted block matches the requested hash. The other device MAY reuse a block from a different file and offset having the same size and hash if one exists.
The from_temporary field is set to indicate that the read should be performed from the temporary file (converting the name to its temporary form) and falling back to the permanent file if any error occurs. Knowledge of the contents of temporary files comes from DownloadProgress messages.
Response
The Response message is sent in response to a Request message.
Protocol Buffer Schema
message Response {
int32 id \= 1;
bytes data \= 2;
ErrorCode code \= 3;
}
enum ErrorCode {
NO\_ERROR \= 0;
GENERIC \= 1;
NO\_SUCH\_FILE \= 2;
INVALID\_FILE \= 3;
}
Fields
The id field is the request identifier. It must match the ID of the Request that is being responded to.
The data field contains either the requested data block or is empty if the requested block is not available.
The code field contains an error code describing the reason a Request could not be fulfilled, in the case where zero-length data was returned. The following values are defined:
- No Error (data should be present)
- Generic Error
- No Such File (the requested file does not exist, or the offset is outside the acceptable range for the file)
- Invalid (file exists but has an invalid bit set or is otherwise unavailable)
DownloadProgress
The DownloadProgress message is used to notify remote devices about the partial availability of files. By default, these messages are sent every 5 seconds, and only in cases where progress or state changes have been detected. Each DownloadProgress message is addressed to a specific folder and MUST contain zero or more FileDownloadProgressUpdate messages.
Protocol Buffer Schema
message DownloadProgress {
string folder \= 1;
repeated FileDownloadProgressUpdate updates \= 2;
}
message FileDownloadProgressUpdate {
FileDownloadProgressUpdateType update\_type \= 1;
string name \= 2;
Vector version \= 3;
repeated int32 block\_indexes \= 4;
}
enum FileDownloadProgressUpdateType {
APPEND \= 0;
FORGET \= 1;
}
Fields (DownloadProgress Message)
The folder field represents the ID of the folder for which the update is being provided.
The updates field is a list of progress update messages.
Fields (FileDownloadProgressUpdate Message)
The update_type indicates whether the update is of type append (0) (new blocks are available) or forget (1) (the file transfer has completed or failed).
The name field defines the file name from the global index for which this update is being sent.
The version message defines the version of the file for which this update is being sent.
The block_indexes field is a list of positive integers, where each integer represents the index of the block in the FileInfo message Blocks array that has become available for download.
For example, an integer with value 3 represents that the data defined in the fourth BlockInfo message of the FileInfo message of that file is now available. Please note that matching should be done on name AND version. Furthermore, each update received is incremental, for example, the initial update message might contain indexes 0, 1, and 2, and an update 5 seconds later might contain indexes 3, 4, and 5 which should be appended to the original list, which implies that blocks 0-5 are currently available.
Block indexes MAY be added in any order. An implementation MUST NOT assume that block indexes are added in any specific order.
The forget field being set implies that the previously advertised file is no longer available, therefore the list of block indexes should be truncated.
Messages with the forget field set MUST NOT have any block indexes.
Any update message that is being sent for a different version of the same file name must be preceded with an update message for the old version of that file with the forget fieldset.
As a safeguard on the receiving side, the value of version changing between update messages implies that the file has changed and that any indexes previously advertised are no longer available. The list of available block indexes MUST be replaced (rather than appended) with the indexes specified in this message.
Ping
The Ping message is used to determine that a connection is alive and to keep connections alive through state-tracking network elements such as firewalls and NAT gateways. A Ping message is sent every 90 seconds if no other message has been sent in the preceding 90 seconds.
Protocol Buffer Schema
message Ping {
}
Close
The Close message MAY be sent to indicate that the connection will be torn down due to an error condition. A Close message MUST NOT be followed by further messages.
Protocol Buffer Schema
message Close {
string reason = 1;
}
Fields
The reason field contains a human-readable description of the error condition.
Sharing Modes
Trusted
Trusted mode is the default sharing mode. Updates are exchanged in both directions.
+------------+ Updates /---------\\
| | \-----------> / \\
| Device | | Cluster |
| | <----------- \\ /
+------------+ Updates \\\---------/
Send Only
In send-only mode, a device does not apply any updates from the cluster but publishes changes in its local folder to the cluster as usual.
+------------+ Updates /---------\\
| | \-----------> / \\
| Device | | Cluster |
| | \\ /
+------------+ \\\---------/
Receive Only
In receive-only mode, a device does not send any updates to the cluster but accepts changes to its local folder from the cluster as usual.
+------------+ Updates /---------\\
| | <----------- / \\
| Device | | Cluster |
| | \\ /
+------------+ \\\---------/
Delta Index Exchange
Index data must be exchanged whenever two devices connect so that one knows the files available on the other. In the most basic case, this happens by way of sending an Index
message followed by one or more Index Update
messages. Any previous index data known for a remote device is removed and replaced with the new index data received in an Index
message, while the contents of an Index Update
message are simply added to the existing index data.
For situations with large indexes or frequent reconnects this can be quite inefficient. A mechanism can then be used to retain index data between connections and only transmit any changes since that data on the connection starts. This is called “delta indexes”. To enable this mechanism the sequence and index ID fields are used.
Sequence:
Each index item (i.e., file, directory, or symlink) has a sequence number field. It contains the value of a counter at the time the index item was updated. The counter increments by one for each change. That is, as files are scanned and added to the index they get assigned sequence numbers 1, 2, 3, and so on. The next file to be changed or detected gets sequence number 4, and future updates continue in the same fashion.
Index ID:
Each folder has an Index ID. This is a 64-bit random identifier set at index creation time.
Given the above, we know that the tuple {index ID, maximum sequence number} uniquely identifies a point in time of a given index. Any further changes will increase the sequence number of some items, and thus the maximum sequence number for the index itself. Should the index be reset or removed (i.e., the sequence number reset to zero), a new index ID must be generated.
By letting a device know the {index ID, maximum sequence number} we have for their index data, that device can arrange to only transmit Index Update
messages for items with a higher sequence number. This is the delta index mechanism.
The index ID and maximum sequence number known for each device are transmitted in the Cluster Config
message at the connection start.
For this mechanism to be reliable outgoing index information must be ordered by increasing sequence number. Devices announcing a non-zero index ID in the Cluster Config
message MUST send all index data ordered by increasing sequence number. Devices not intending to participate in delta index exchange MUST send a zero index ID or, equivalently, not send the index_id
attribute at all.
Message Limits
An implementation MAY impose reasonable limits on the length of messages and message fields to aid robustness in the face of corruption or broken implementations. An implementation should strive to keep messages short and to the point, favoring more and smaller messages over fewer and larger ones. For example, favor a smaller Index message followed by one or more Index Update messages rather than sending a very large Index message.
The Syncthing implementation imposes a hard limit of 500,000,000 bytes on all messages. Attempting to send or receive a larger message will result in a connection close. This size was chosen to accommodate Index messages containing a large block list. It’s intended that the limit may be further reduced in a future protocol update supporting variable block sizes (and thus shorter block lists for large files).
Selection of Block Size
The desired block size for any given file is the smallest block size that results in fewer than 2,000 blocks, or the maximum block size for larger files. This rule results in the following table of block sizes per file size:
| File Size | Block Size |
| --- | --- |
| 0 - 250 MiB | 128 KiB |
| 250 MiB - 500 MiB | 256 KiB |
| 500 MiB - 1 GiB | 512 KiB |
| 1 GiB - 2 GiB | 1 MiB |
| 2 GiB - 4 GiB | 2 MiB |
| 4 GiB - 8 GiB | 4 MiB |
| 8 GiB - 16 GiB | 8 MiB |
| 16 GiB - up | 16 MiB |
An implementation MAY deviate from the block size rule when there is good reason to do so. For example, if a file has been indexed at a certain block size and grows beyond 2000 blocks it may be retained at the current block size for practical reasons. When there is no overriding reason to the contrary, such as when indexing a new file for the first time, the block size rule above SHOULD be followed.
An implementation MUST therefore accept files with a block size differing from the above rule. This does not mean that arbitrary block sizes are allowed. The block size used MUST be exactly one of the power-of-two block sizes listed in the table above.
Example Exchange
| # | A | B |
| --- | --- | --- |
| 1 | ClusterConfiguration-> | <-ClusterConfiguration |
| 2 | Index-> | <-Index |
| 3 | IndexUpdate-> | <-IndexUpdate |
| 4 | IndexUpdate-> | |
| 5 | Request-> | |
| 6 | Request-> | |
| 7 | Request-> | |
| 8 | Request-> | |
| 9 | | <-Response |
| 10 | | <-Response |
| 11 | | <-Response |
| 12 | | <-Response |
| 13 | Index Update-> | |
| … | | |
| 14 | | <-Ping |
| 15 | Ping-> | |
The connection is established and at 1. both peers send ClusterConfiguration messages and then Index records. The Index records are received and both peers recompute their knowledge of the data in the cluster. In this example, peer A has four missing or outdated blocks. At 5 through 8 peer A sends requests for these blocks. The requests are received by peer B, who retrieves the data from the folder and transmits Response records (9 through 12). Device A updates its folder contents and transmits an Index Update message (13). Both peers enter an idle state after 13. At some later time 14, the ping timer on device B expires and a Ping message is sent. The same process occurs for device A at 15.
Examples of Strong Cipher Suites
| ID | Name | Description |
| --- | --- | --- |
| 0x009F | DHE-RSA-AES256-GCM-SHA384 | TLSv1.2 DH RSA AESGCM(256) AEAD |
| 0x006B | DHE-RSA-AES256-SHA256 | TLSv1.2 DH RSA AES(256) SHA256 |
| 0xC030 | ECDHE-RSA-AES256-GCM-SHA384 | TLSv1.2 ECDH RSA AESGCM(256) AEAD |
| 0xC028 | ECDHE-RSA-AES256-SHA384 | TLSv1.2 ECDH RSA AES(256) SHA384 |
| 0x009E | DHE-RSA-AES128-GCM-SHA256 | TLSv1.2 DH RSA AESGCM(128) AEAD |
| 0x0067 | DHE-RSA-AES128-SHA256 | TLSv1.2 DH RSA AES(128) SHA256 |
| 0xC02F | ECDHE-RSA-AES128-GCM-SHA256 | TLSv1.2 ECDH RSA AESGCM(128) AEAD |
| 0xC027 | ECDHE-RSA-AES128-SHA256 | TLSv1.2 ECDH RSA AES(128) SHA256 |
Ref: GitHub Syncthing Doc
Top comments (0)
