Kubernetes Setup

#devops #kubernetes #application #deployment

Install and configure Kubernetes on both Windows and Ubuntu

On Windows

Install Docker Desktop:
- Download Docker Desktop from the official Docker website.
- Run the installer and follow the on-screen instructions.
Install kubectl:
- Open PowerShell as an administrator.
- Run the following command to download kubectl:
```
 curl.exe -LO "https://dl.k8s.io/release/v1.31.0/bin/windows/amd64/kubectl.exe"
```

Validate the binary (optional):

 curl.exe -LO "https://dl.k8s.io/release/v1.31.0/bin/windows/amd64/kubectl.exe.sha256"
 CertUtil -hashfile kubectl.exe SHA256
 type kubectl.exe.sha256

Move the binary to a directory in your PATH:

 mkdir -p $HOME/bin
 mv .\kubectl.exe $HOME\bin\kubectl.exe

Add the directory to your PATH environment variable.

Install Minikube:
- Download Minikube from the official Minikube releases page.
- Run the installer and follow the instructions.
Start Minikube:
- Open a new command prompt and run:
```
 minikube start
```

On Ubuntu

Update the package list and install dependencies:

   sudo apt-get update
   sudo apt-get install -y apt-transport-https ca-certificates curl

Download the Google Cloud public signing key:

   curl -s https://packages.cloud.google.com/apt/doc/apt-key.gpg | sudo apt-key add -

Add the Kubernetes APT repository:

   sudo bash -c 'cat <<EOF >/etc/apt/sources.list.d/kubernetes.list
   deb https://apt.kubernetes.io/ kubernetes-xenial main
   EOF'

Install Kubernetes components:

   sudo apt-get update
   sudo apt-get install -y kubelet kubeadm kubectl
   sudo apt-mark hold kubelet kubeadm kubectl

Initialize the Kubernetes cluster:

   sudo kubeadm init

Set up the local kubeconfig:

   mkdir -p $HOME/.kube
   sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config
   sudo chown $(id -u):$(id -g) $HOME/.kube/config

Install a pod network add-on (e.g., Calico):

   kubectl apply -f https://docs.projectcalico.org/manifests/calico.yaml

Join worker nodes to the cluster:
- Run the kubeadm join command provided at the end of the kubeadm init output on each worker node.

These steps should get you up and running with Kubernetes on both Windows and Ubuntu.

Deploy an application on Kubernetes

This involves several steps. Here's a general guide to help you get started:

1. Create a Deployment YAML File

First, you need to define your application in a YAML file. This file will describe the desired state of your application, including the container image, number of replicas, and other configurations.

Here's an example of a simple deployment YAML file:

apiVersion: apps/v1
kind: Deployment
metadata:
  name: my-app
spec:
  replicas: 3
  selector:
    matchLabels:
      app: my-app
  template:
    metadata:
      labels:
        app: my-app
    spec:
      containers:
      - name: my-app-container
        image: my-app-image:latest
        ports:
        - containerPort: 80

2. Apply the Deployment

Use the kubectl apply command to create the deployment in your Kubernetes cluster:

kubectl apply -f my-app-deployment.yaml

3. Expose the Deployment

To make your application accessible, you need to expose it using a Service. Here's an example of a Service YAML file:

apiVersion: v1
kind: Service
metadata:
  name: my-app-service
spec:
  selector:
    app: my-app
  ports:
    - protocol: TCP
      port: 80
      targetPort: 80
  type: LoadBalancer

Apply the Service configuration:

kubectl apply -f my-app-service.yaml

4. Verify the Deployment

Check the status of your deployment and service:

kubectl get deployments
kubectl get services

5. Access Your Application

If you used a LoadBalancer type service, you can access your application using the external IP address provided by the service. You can find this IP address by running:

kubectl get services my-app-service

Additional Tips

Scaling: You can scale your application by updating the replicas field in your deployment YAML file and reapplying it.
Updating: To update your application, modify the container image in the deployment YAML file and apply the changes.
Monitoring: Use kubectl logs and kubectl describe to troubleshoot and monitor your application.

Ref: https://kubernetes.io/docs/setup/
